Eaton SKU 5PX2000IRT2UAUG2

Eaton 5PX2000IRT2UAUG2 5PX Gen 2 2000VA/2000W 2U Rack/Tower UPS

The Eaton 5PX2000IRT2UAUG2 5PX Gen 2 is a 230V line-interactive pure-sine-wave UPS rated at 2000VA / 2000W in a rack/tower format.

The supplied connection set lists 1 x IEC 60320 C14 (10A) input and 8 x IEC 60320 C13 (10A), with RS-232 serial, USB HID, a communication-card slot and ROO/RPO terminals.

2000VA / 2000WPure sine wave2U rack/tower3-year warrantyDeviceDeal authorised Eaton reseller

Product overview

2000VA / 2000W

The supplied VA and watt ratings are equal, with pure-sine-wave output stated.

Rack or tower deployment

The product is supplied as a rack/tower UPS with a 2U description and replaceable hot-swappable battery.

Management connectivity

The source lists a graphical LCD, RS-232 serial, USB HID, communication-card slot and Network-M2 or Relay-MS management-card options.

Source review: Source review: The structured fields label the dimensions as height 438mm, width 603mm and depth 85.5mm, which appears inconsistent with the supplied 2U rack-height description; the source labels are preserved and require confirmation.

Frequently asked questions

What power rating is listed for the Eaton 5PX2000IRT2UAUG2?

The supplied load capacity is 2000VA / 2000W.

What input and output connections are listed?

The source lists 1 x IEC 60320 C14 (10A) input and 8 x IEC 60320 C13 (10A).

Is the battery replaceable while installed?

The supplied specification lists the battery as replaceable and hot swappable.

What warranty is supplied?

The source lists a three-year Eaton manufacturer warranty.

(5PX2000IRT2UAUG2)

Features

Eaton 5PX2000IRT2UAUG2 5PX Gen 2 2000VA/2000W 2U Rack/Tower UPS

Power performance

Line-interactive topology
Pure sine wave
Load capacity: 2000VA / 2000W
Nominal voltage stated: 230V

Connections

1 x IEC 60320 C14 (10A)
8 x IEC 60320 C13 (10A)
RS-232 serial
USB HID
Communication-card slot
ROO / RPO terminals

Operation and installation

Graphical LCD
Replaceable hot-swappable battery
Rack / tower form factor
Rack-height field: 2U
40dB sound emission
40°C maximum operating temperature

Confirm the supplied physical-dimension labels and rack-height details before installation.

Technical specifications

Eaton 5PX2000IRT2UAUG2 5PX Gen 2 2000VA/2000W 2U Rack/Tower UPS

General and power
Brand	Eaton
Model / SKU	5PX2000IRT2UAUG2
Series	5PX G2
Product type	Line-interactive UPS
Topology / waveform	Line-interactive; pure sine wave
Load capacity	2000VA / 2000W
Nominal voltage stated in description	230V
Structured input-voltage values	230V AC; 120V AC
Structured output-voltage values	200V AC; 208V AC; 220V AC; 230V AC; 240V AC
Input voltage ranges listed	150294V AC; 160294V AC
Description input-frequency ranges	4770Hz (50Hz); 56.570Hz (60Hz)
Structured input frequency	70Hz
Structured output frequency	60Hz
Connections and receptacles
Input connector	1 x IEC 60320 C14 (10A)
Output receptacles	8 x IEC 60320 C13 (10A)
Serial port	Yes
USB HID-compliant port	Yes
Communication card slot	Stated in description
Terminals	ROO / RPO
Network-management options	Network-M2 card; Relay-MS card
Battery, display and environment
Hot-swappable battery	Yes
Replaceable battery	Yes
Status display	Graphical LCD display
Sound emission	40dB
Maximum operating temperature	40°C
Physical properties
Form factor	Rack / tower
Rack-height field	2U
Height field	438mm
Width field	603mm
Depth field	85.5mm
Approximate weight	28kg
Applications listed
Application / usage	Server; Storage device; Switch; Router
Package contents
Included items	5PX G2 2000VA rack/tower UPS; rack kit

SKU	5PX2000IRT2UAUG2
Barcode #	743172104830
Brand	EATON
Shipping Weight	34.0000kg
Shipping Width	0.024m
Shipping Height	0.079m
Shipping Length	0.059m

Warranty information

Eaton 5PX2000IRT2UAUG2 5PX Gen 2 2000VA/2000W 2U Rack/Tower UPS

3-Year Eaton Manufacturer Warranty

DeviceDeal is an authorised Eaton reseller. This product is covered by a three-year Eaton manufacturer warranty in Australia, as listed in the supplied product information.
