System Main Processor Embedded processor Memory 256 Mb Input/Output Ports Input Inputs x 20 ( Lock state x 4, Door sensor x 4, Exit button x 4, Alarm x 8) Output Relay x 12(Door lock x 4, Alarm x 8 ) Reader Reader x 4 Capacity Card holders 200,000 Events 150,000 Function Control Mode Four door one-way Access control Anti-pass back, Multi-interlock, Multi-card unlock User Management General, VIP, Guest, Patrol, Blocklist, Duress Alarm Function Door time out alarm, Intrusion alarm, Duress alarm, Tamper alarm Period Support 128 groups of schedule, 128 groups of period and 128 groups of holiday period Interface To PC RJ45(10/100M) To Reader Wiegand 26/34, RS485 Network Network Function TCP/IP, UDP, HTTP, HTTPS, DDNS, Register, P2P, NTP, DST Max. User Access 1-999 adjustable Genreal RTC Yes Power Supply AC85-AC264, 50/60Hz Operating Temperature –30°C to +60°C Working Humidity ?95% Dimension(W×D×H) 330.0 mm × 270.0 mm × 87.0 mm Weight 2 kg Working Environment Indoor Certificates CE Yes FCC Yes
