APC Smart-UPS SRT 1500VA RM 230V Network Card
Model # SRT1500RMXLI-NC
-
SKU: SRT1500RMXLI-NC
- Pick Up Available
- Australian Warranty
- Checkout Securely
APC Smart-UPS On-Line, 1500VA/1500W, Rackmount 2U, 230V, 6x C13 IEC outlets, Network Card, Extended runtime, W/ rail kit
SKU: SRT1500RMXLI-NC | Brand: APC Brand
Key Features
- <a>Replacement battery (1)</a> is available
- 1500VA/1500W double-conversion on-line pure sine wave 2U rackmount UPS
- Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
- Rack/Tower convertible (rail kit included)
- 1-Year Secure Network Management Card subscription included
- Add up to 10 external battery packs (SRT48RMBP) for extended runtime
Description
This product is part of the Smart-UPS On-Line range that provides high density, true double-conversion on-line power protection.
This 1500VA/1500W On-line pure sine wave UPS provides scalable runtime while minimizing maintenance.
The 2U rackmount SRT has a preinstalled Network Management Card in the Smart Slot for UPS network-based monitoring and management.
PowerChute network shutdown provides graceful, unattended shutdown of critical IT equipment ranging from physical servers and virtual machines to HCI cluster.
It comes with BS1363A British, IEC 60320 C20, and Schuko CEE 7/EU1-16P inputs, 6x IEC 60320 C13 outlets.
The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty.
Its dimensions are 505mm (depth) x 85mm (height) x 432mm (width) and weighs 21.00kg.
Ideal for servers, voice/data networks, medical labs, and light industrial applications.
It conforms to CE and EAC.
Designed for IT professionals or network administrators providing wide input voltage window, tight output voltage regulation, frequency regulation, internal bypass, and input power factor correction.
Product Images
Downloads & Documents
Compatible Products & Accessories
Mounting
Racks
ER6482
APC Easy Rack, 24U, Black, With Roof, Castors, Feet, 4 Brack...
ER6222
APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...
ER6212
APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...
ER6202
APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...
ER6282
APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...
ER8222
APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...
ER8212
APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...
ER8202
APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...
ER8282
APC Easy Rack, 42U, Black, With Roof, Castors, Feet, 4 Brac...
ER6822
APC Easy Rack, 48U, Black, With Roof, Castors, Feet, 4 Brack...
ER6812
APC Easy Rack, 48U, Black, With Roof, Castors, Feet, 4 Brack...
ER6802
APC Easy Rack, 48U, Black, With Roof, Castors, Feet, 4 Brack...
Replacement battery
Sensors
SmartSlot
AP9620
Protocol translation to UPS-Link, Management Options, Legacy...
AP9640
Device monitoring and management, Network Management Cards, ...
AP9641
Device monitoring and management, Network Management Cards, ...
AP9643
Device monitoring and management, Network Management Cards, ...
AP9810
Dry contact, Management Options, Dry Contact I/O Accessory, ...
(SRT1500RMXLI-NC)
Specifications - SRT1500RMXLI-NC
Overview
| Presentation | High density, double-conversion on-line power protection with scalable runtime. |
| Lead time | Usually in Stock |
Main
| Main Input Voltage | 230 V AC 1 phase |
| Input voltage | 220 V |
| Input Connection Type | BS1363A British IEC 60320 C14 Schuko CEE 7 / EU1-16P |
| Input voltage limits | 100...275 V 40% load 176...275 V full load |
| Network frequency | 40...70 Hz auto-sensing |
| Output voltage | 220 V 240 V |
| Rated power in W | 1500 W |
| rated power in VA | 1500 VA |
| Output connection type | 6 IEC 60320 C13 |
| Bypass type | Built-in bypass |
| Crest factor | 3 : 1 |
| Harmonic distortion | Less than 2 % |
| Maximum configurable power in VA | 1500 VA |
| Maximum configurable power in W | 1500 W |
| UPS type | On-Line |
| Wave type | Sine wave |
| Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
Complementary
| Battery type | Lead-acid internal included |
| Emergency power off | Yes |
| Free slots | 0 |
| Preinstalled device | Network management card 3 with environmental monitoring |
| Alarm | Audible and visible alarms : prioritized by severity |
| UPS connectivity | Serial port USB port Pre-installed network management card 3 |
| Surge energy rate | 432 J |
| Number of rack unit | 2U |
| Cable length | 1.8 m |
| Number of cables | 1 |
| Colour | Black |
| Height | 85 mm |
| Width | 432 mm |
| Depth | 505 mm |
| Net weight | 21 kg |
| Mounting location | Rack |
| Mounting preference | No preference |
| Mounting mode | Rack-mounted with included kit |
| Two post mountable | 0 |
| USB compatible | Yes |
| Mounting position | Vertical |
| Provided equipment | CD with software Communication cable Country-specific detachable power cord Documentation CD Installation guide Network management card Rack mounting hardware Rack mounting brackets Rack mounting support rails Temperature probe USB cable Warranty card |
| Number of power module filled slots | 0 |
| Number of power module free slots | 0 |
| Additional specification | High density |
| Redundant | No |
| Range of product | Smart-UPS On-Line |
| Product or component type | Uninterruptible power supply (UPS) |
Environment
| Product certifications | CE EAC UK PSTI |
| Marking | CE Mark |
| Standards | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
| Ambient air temperature for operation | 0…40 °C |
| Ambient air temperature for storage | -20…50 °C |
| Storage altitude | 0…15240 m |
| IP degree of protection | IP20 |
| Relative humidity | 0…95 % non-condensing |
| Storage Relative Humidity | 0…95 % non-condensing |
| Acoustic level | 50 dBA |
| Heat dissipation | 317 Btu/h |
| Operating altitude | 0...10000 ft |
Batteries & Runtime
| Run Time | View Runtime Graph |
| Efficiency | View Efficiency Graph |
| Battery type | Lead-acid battery |
| Battery voltage | 48 V |
| Extended runtime | 1 |
| Number of battery filled slots | 1 |
| Number of battery free slots | 0 |
| Battery recharge time | 3 h |
| Number of battery replacement quantity | 1 |
| Battery life | 3…5 year(s) |
| Replacement battery | APCRBC155 |
| Battery charger power | 108 W rated |
Packing Units
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 24.5 cm |
| Package 1 Width | 69 cm |
| Package 1 Length | 59.5 cm |
| Package 1 Weight | 32.58 kg |
Contractual warranty
| Warranty (in months) | 24 Battery|36 UPS |
| SKU | SRT1500RMXLI-NC |
| Barcode # | 731304340294 |
| Brand | APC |
| Shipping Weight | 29.6000kg |
| Shipping Width | 0.024m |
| Shipping Height | 0.074m |
| Shipping Length | 0.060m |
