Critical Power, Cooling and Racks > Uninterruptible Power Supply (UPS) > Network and Server > Smart-UPS > SMX1500RMI2UNC

APC Smart-UPS X, Line Interactive, 1500VA, Rack/tower convertible 2U, 230V, 8x C13 IEC, Network card, Extended runtime

SKU: SMX1500RMI2UNC | Brand: APC Brand

Key Features

<a>Replacement battery (1)</a> is available
1440VA/1200W line interactive pure sine wave 2U rack/tower UPS (rail kit included)
Add up to 5 external battery packs (SMX48RMBP2U)
Preinstalled NMC for network-based UPS monitoring & management
1-Year Secure Network Management Card subscription included
Automatic Voltage Regulation keeps output voltage within acceptable user selectable levels

Description

This product is part of the Smart-UPS range, an intelligent and efficient network power protection offer from entry-level to scalable runtime.
This 1500VA/1200W premium and reliable line-interactive UPS provides pure sine wave and scalable runtime for critical applications.
The 2U rack/tower convertible SMX has a preinstalled Network Management Card in the Smart Slot for UPS network-based monitoring and management.
PowerChute network shutdown provides graceful, unattended shutdown. The UPS has extendable batteries (up to 10) for more runtime during prolonged outages.
It comes with IEC 320 C14 input, 8x IEC 320 C13 outlets, and 2x IEC jumper cables.
The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty.
Its dimensions are 490mm (depth) x 89mm (height) x 432mm (width) and weighs 24.82kg.
Ideal for server rooms, network closets, business VoIP, data storage, and network-attached storage (NAS) and small datacenters.
It conforms to C-Tick, CE, VDE, and EAC, EN/IEC 62040-1/62040-2.

Product Images

Downloads & Documents

Compatible Products & Accessories

Batteries

SMX48RMBP2U

APC Smart-UPS X-Series External Battery Pack Rack/Tower 48V,...

Mounting

AP9625

APC SmartUPS/SmartUPS RT 2 Post Rail Kits

PDU

AP6015A

RACK PDU, BASIC, 0U/1U, 120-240V/15A, 220-240V/10A, (8) C13

AP7820B

Rack PDU, Metered, 1U, 12A/208V, 10A/230V, (8) C13

AP7850B

Rack PDU, Metered, Zero U, 10A, 230V, (16) C13

AP7920B

APC NetShelter Switched Rack PDU, 1U, 1PH, 2.3kW 230V 10A or...

AP7950B

Rack PDU, Switched, Zero U, 10A, 230V, (16) C13

AP8702R-WW

Power Cord Kit (6 ea), Locking, C13 TO C14 (90 Degree), 0.6m

AP8702S-WW

Power Cord Kit (6 ea), Locking, C13 to C14, 0.6m

AP8702S-WWX340

Power Cord Kit (6 ea), Locking, C13 TO C14, 0.6m, Red

AP8702S-WWX590

Power Cord Kit (6 ea), Locking, C13 TO C14, 0.6m, Blue

AP8704R-WW

Power Cord Kit (6 ea), Locking, C13 to C14 (90 Degree), 1.2m

AP8704S-WW

Power Cord Kit (6 ea), Locking, C13 to C14, 1.2m

AP8704S-WWX340

Power Cord Kit (6 ea), Locking, C13 to C14, 1.2m, Red

Racks

AR3130

APC NetShelter SX, Server Rack Enclosure, 42U, Black, 1991H ...

AR3140

APC NetShelter SX, Networking Rack Enclosure, 42U, Black, 19...

AR3140W

APC NetShelter SX, Networking Rack Enclosure, 42U, White, 19...

AR3150

APC NetShelter SX, Server Rack Enclosure, 42U, Black, 1991.4...

AR3150SP

APC NetShelter SX, Server Rack Enclosure, 42U, Shock Packagi...

AR3150W

APC NetShelter SX, Server Rack Enclosure, 42U, White, 2258H ...

AR201

NetShelter 2 Post Rack 45U #12-24 Threaded Holes Black

AR3155

APC NetShelter SX, Server Rack Enclosure, 45U, Black, 2124H ...

AR3155SP

APC NetShelter SX, Server Rack Enclosure, 45U, Shock Packagi...

AR3157

APC NetShelter SX, Server Rack Enclosure, 48U, Black, 2258H ...

AR3157SP

APC NetShelter SX, Server Rack Enclosure, 48U, Shock Packagi...

AR3200

APC NetShelter SX, Server Rack Enclosure, Colocation, 42U, B...

Replacement battery

APCRBC115

APC Replacement Battery Cartridge for Smart-UPS Line Interac...

Sensors

AP9335T

Wired, Sensor, NetBotz, Temperature, 13 ft

AP9335TH

APC Temperature & Humidity Sensor

Service bypass panels

SBP1500RMI

APC SERVICE BYPASS PDU, 230V 10AMP W/ (6) IEC C13

SmartSlot

AP9620

Protocol translation to UPS-Link, Management Options, Legacy...

AP9640

Device monitoring and management, Network Management Cards, ...

AP9641

Device monitoring and management, Network Management Cards, ...

AP9643

Device monitoring and management, Network Management Cards, ...

AP9810

Dry contact, Management Options, Dry Contact I/O Accessory, ...

Subscriptions

SWNMC3SU-1Y-DIGI

Subscription, Network Management Cards, 1 year, Secure NMC S...

SWNMC3SU-3Y-DIGI

Subscription, Network Management Cards, 3 year, Secure NMC S...

SWNMC3SU-5Y-DIGI

Subscription, Network Management Cards, 5 year, Secure NMC S...

SWNMC3SU-6Y-DIGI

Subscription, Network Management Cards, 6 year, Secure NMC S...

SWNMC3SU-4Y-DIGI

Subscription, Network Management Cards, 4 year, Secure NMC S...

SWNMC3SU-2Y-DIGI

Subscription, Network Management Cards, 2 year, Secure NMC S...

(SMX1500RMI2UNC)

Specifications - SMX1500RMI2UNC

Overview

Presentation	Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
Lead time	Usually Ships within 2 Weeks

Main

Main Input Voltage	230 V AC 1 phase
Input Connection Type	IEC 320 C14
Switching current capacity	10 A
Input voltage limits	151...302 V adjustable 160...286 V
Network frequency	50/60 Hz +/- 3 Hz auto-sensing
Output voltage	230 V AC 1 phase
Rated power in W	1200 W
rated power in VA	1500 VA
Output connection type	8 IEC 320 C13 2 IEC Jumpers
Harmonic distortion	Less than 5 %
Maximum configurable power in VA	1500 VA
Maximum configurable power in W	1200 W
UPS type	Line interactive
Wave type	Sine wave
Output frequency	50/60 Hz +/- 3 Hz sync to mains

Complementary

Battery type	Lead-acid internal included
Control panel	Multifunction LCD status and control console
Emergency power off	Yes
Free slots	0
Preinstalled device	Network management card 3 with environmental monitoring
Alarm	Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
UPS connectivity	Serial port USB port Pre-installed network management card 3
Surge energy rate	645 J
Noise suppression	Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
Number of rack unit	2U
Cable length	1.8 m
Number of cables	1
Colour	Black
Height	89 mm
Width	432 mm
Depth	490 mm
Net weight	24.82 kg
Mounting preference	Lower
Mounting mode	Rack-mounted with included kit
Two post mountable	0
USB compatible	Yes
Provided equipment	CD with software Documentation CD Installation guide Rack mounting support rails Removable support feet Smart UPS signalling RS-232 cable USB cable
Number of power module	0
Number of power module filled slots	0
Number of power module free slots	0
Additional specification	Network card pre-installed
Redundant	No
Range of product	Smart-UPS
Product or component type	Uninterruptible power supply (UPS)

Environment

Product certifications	C-Tick CE VDE EAC UK PSTI
Standards	EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018
Ambient air temperature for operation	0…45 °C
Ambient air temperature for storage	-15…45 °C
Storage altitude	0…15240 m
Relative humidity	0…95 %
Storage Relative Humidity	0…95 %
Acoustic level	40 dBA
Heat dissipation	133 Btu/h
Operating altitude	0...10000 ft

Batteries & Runtime

Run Time	View Runtime Graph
Efficiency	View Efficiency Graph
Battery type	Lead-acid battery
Extended runtime	0
Number of battery filled slots	0
Number of battery free slots	0
Battery recharge time	3 h
Number of battery replacement quantity	1
Battery life	3…5 year(s)
Replacement battery	APCRBC115
Battery charger power	103 W rated

Packing Units

Unit Type of Package 1	PCE
Number of Units in Package 1	1
Package 1 Height	24.6 cm
Package 1 Width	58.9 cm
Package 1 Length	62 cm
Package 1 Weight	30 kg
Unit Type of Package 2	PAL
Number of Units in Package 2	16
Package 2 Height	135 cm
Package 2 Width	100 cm
Package 2 Length	120 cm
Package 2 Weight	514.88 kg

Contractual warranty

Warranty (in months)

24 Battery|36 UPS

SKU	SMX1500RMI2UNC
Brand	APC
Shipping Weight	32.0000kg
Shipping Width	0.600m
Shipping Height	0.260m
Shipping Length	0.620m
Shipping Cubic	0.096720000m3
